UpMap MIntake Honda

With UpMap MIntake Honda accessorise is possible to improve the performance of your Honda X-ADV (2021-2023) and Honda Forza (2021-2023).

From the experience of UpMap’s R&D are born the air-intake kits called MIntake. After installation, the MIntake KIT increase the air flow and the air speed intake duct; this allows into more power and torque to the engine.

The dyno graph ^(*1) shows the real potential of the MIntake kit, the test was performed with the same exhaust system configuration.

Increase in power and torque after installation of the MIntake kit

Power +2,4cv e 0,4Kg-M

(^*1Reference model Honda X-Adv Euro 5)

Dedicated maps for the kit MIntake Honda X-ADV EU5 (base and 35Kw version)

CATEGORY: OEM
Code: XADV 21 OEM MINTAKE

Stock exhaust. As for power, mapping reaches 52.44* CV at 6500 Rpm. For torque, a value of 6.63* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: AKRAPOVIC
Code: XADV 21 AK SO MINTAKE

Akrapovic CE approved Slip-On (code: S-H7SO4-xxx). As for power, mapping reaches 52.97* CV at 6600 Rpm. For torque, a value of 6.67* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: AKRAPOVIC
Code: XADV 21 AK FO MINTAKE

Akrapovic CE approved Slip-On (code: S-H7SO4-xxx)  and Akrapovic racing header (code: E-H7R1). As for power, mapping reaches 53.53* CV at 6200 Rpm. For torque, a value of 6.89* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: ARROW
Code: XADV 21 AW SO MINTAKE

Arrow Slip-On (code: 71864xxx) with baffle. As for power, mapping reaches 52.97* CV at 6600 Rpm. For torque, a value of 6.67* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: ARROW
Code: XADV 21 AW FO MINTAKE

Arrow Slip-On (code: 71864xxx) and Arrow racing header (code: 71671MI) with baffle. As for power, mapping reaches 53.53* CV at 6200 Rpm. For torque, a value of 6.89* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: TERMIGNONI
Code: XADV 21 H176 SO MINTAKE

Termignoni CE approved Slip-On (code: H176). As for power, mapping reaches 52.84* CV at 6500 Rpm. For torque, a value of 6.69* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: TERMIGNONI
Code: XADV 21 H176 FO MINTAKE

Termignoni full racing exhaust (code: H176). As for power, mapping reaches 53.62* CV at 6200 Rpm. For torque, a value of 6.90* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: OEM
Code: XADV 21 OEM N AW MINTAKE

Stock exhaust and Arrow racing header (code: 71671MI) without baffle. As for power, mapping reaches 53.22* CV at 6600 Rpm. For torque, a value of 6.79* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: OEM
Code: XADV 21 OEM N H176 MINTAKE

Stock exhaust and Termignoni racing header (code: H176) senza db-killer. As for power, mapping reaches 53.30* CV at 6600 Rpm. For torque, a value of 6.78* Kgm at 4900 Rpm. [*The data shown are wheel values]

CATEGORY: SC-PROJECT
Code: XADV 21 SC SO MINTAKE

SC-Project Slip-On (code: SCP-H41A-xxx) con db-killer. As for power, mapping reaches 52.96* CV at 6600 Rpm. For torque, a value of 6.65* Kgm at 4800 Rpm. [*The data shown are wheel values]

Dedicated maps for the kit MIntake Honda Forza EU5 (base and 35Kw version)

CATEGORY: OEM
Code: FORZA 21 OEM MINTAKE

Stock exhaust. As for power, mapping reaches 52.44* CV at 6500 Rpm. For torque, a value of 6.63* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: AKRAPOVIC
Code: FORZA 21 AK SO MINTAKE

Akrapovic CE approved Slip-On (code: S-H7SO4-xxx).

CATEGORY: ARROW
Code: FORZA 21 AW SO MINTAKE

Arrow Slip-On (code: 73518xxx) with baffle. As for power, mapping reaches 52.97* CV at 6600 Rpm. For torque, a value of 6.67* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: ARROW
Code: FORZA 21 AW FO MINTAKE

Arrow Slip-On (code: 73518xxx) and Arrow racing header (code: 73019MI) with baffle. As for power, mapping reaches 53.53* CV at 6200 Rpm. For torque, a value of 6.89* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: TERMIGNONI
Code: FORZA 21 H176 SO MINTAKE

Termignoni CE approved Slip-On (code: H176). As for power, mapping reaches 52.84* CV at 6500 Rpm. For torque, a value of 6.69* Kgm at 4800 Rpm. [[*The data shown are wheel values]

CATEGORY: OEM
Code: FORZA 21 OEM N AW MINTAKE

Stock exhaust and Arrow racing header (code: 73019MI) without baffle. As for power, mapping reaches 53.22* CV at 6600 Rpm. For torque, a value of 6.79* Kgm at 4800 Rpm. [*The data shown are wheel values]

CATEGORY: SC-PROJECT
Code: FORZA 21 SC SO MINTAKE

SC-Project Slip-On (code: SCP-H39A-xxx) con db-killer. As for power, mapping reaches 52.96* CV at 6600 Rpm. For torque, a value of 6.65* Kgm at 4800 Rpm. [*The data shown are wheel values]

(*1) With the purchase of the intake kit, other accessories are not included, such as UpMap T800+ devices, or services such as engine calibrations.
(*2) Calibration is available on the UpMap platform. To use this calibration you must have an UpMap device.
(*3) To find out whether your bike is compatible, check the product compatibility table.
